Finger Gold 4-6 Layer 4oz Electronics Pcb Assembly

Product Categories

Beijing Haina Lean Technology Co., Ltd

Contact Now

Finger Gold 4-6 Layer 4oz Electronics Pcb Assembly

Name: Finger Gold 46 Layer 4oz Electronics Pcb Assembly
Brand: HNL-PCBA
Price: 1 USD

Wholesale Finger Gold 4-6 Layer 4oz Electronics Pcb Assembly from china suppliers

Brand Name : HNL-PCBA

Model Number : PCB Assembly 07

Certification : ISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000

Place of Origin : CHINA

MOQ : 1 PC

Price : Negotiable

Payment Terms : T/T, Western Union, L/C, MoneyGram

Supply Ability : 10,000,000 Point /Day

Delivery Time : 1-7days

Packaging Details : ESD packaging with carton box

Product name : pcb Printed Circuit Board Assembly

Material : Fr-4, Fr-5, High-Tg, Aluminum Based , Halogen Free

Number of layers : 1-46layers , Multilayer

Copper thickness : 1oz 2oz 3oz 4oz.... 6oz

Max Board size : 700x610mm, custom

Min. line spacing,Min. line width : 0.030mm , 0.030mm

Board thickness : 0.3-3.5mm

Min. hole size : Laser 0.05mm ; Mechnical 0.15

Surface finishing : HASL,OSP,ENIG,HASL Lead Free,Immersion Gold

Solder mask color : green.Blue.red.black.white.etc

Pcb assembly method : Mixed, BGA, SMT, Through-hole etc.

Service : One-stop Service,PCB; PCBA,ODM and OEM

Contact Now

Multilayer Finger Gold 4-6 layer pcb Printed Circuit Board Assembly

Turnkey PCB Assembly Introduction

Turnkey PCB assembly means that the supplier handles all aspects of PCB solutions, including components procuring and PCB manufacturing, picking and placing components on specific locations on your custom PCBs. In essence, full turnkey PCB assembly gives the buyer greater freedom to focus on PCB design, while the supplier takes care of the rest, which is why it is a leading form of one-stop electronic assembly .

PCB CAPABILITIES

FACTORY CAPABILITIES
No.	Items	2019	2020
1	HDI Capabilities	HDI ELIC (4+2+4)	HDI ELIC(5+2+5)
2	Max layer count	32L	36L
3	Board Thickness	Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm	Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm
4	Min.Hole Size	Laser 0.075mm Mechnical 0.15	Laser 0.05mm Mechnical 0.15
5	Min Line Width/Space	0.035mm/0.035	0.030mm/0.030mm
6	Copper Thickness	1/3oz-4oz	1/3oz-6oz
7	Size Max Panel size	700x610mm	700x610mm
8	Registration Accuracy	+/-0.05mm	+/-0.05mm
9	Routing Accuracy	+/-0.075mm	+/-0.05mm
10	Min.BGA PAD	0.15mm	0.125mm
11	Max Aspect Ratio	10:1	10:1
12	Bow and Twist	0.50%	0.50%
13	Impedance Control Tolerance	+/-8%	+/-5%
14	Daily output	3,000m2 (Max capacity of equipment)	4,000m2 (Max capacity of equipment)
15	Surface Finishing	HASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD
16	Raw Material	FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI

PCBA CAPABILITIES

PCBA Capability
Material Type	Item	Min	Max
PCB	Dimension (length,width,height.mm)	50400.38	6004004.2
	Material	FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC
	Surface finish	HASL,OSP,Immersion gold,Flash Gold Finger
Components	Chip&IC	1005	55mm
	BGA Pitch	0.3mm	-
	QFP Pitch	0.3mm	-

Our advantage

Service value

Independent quotation system to quickly serve the market

PCB manufacturing

High-tech PCB and PCB assembly production line

Material purchasing

A team of experienced electronic component procurement engineers

SMT post soldering

Dust-free workshop, high-end SMT patch processing

Finger Gold 4-6 Layer 4oz Electronics Pcb Assembly

Turnkey PCB Assembly Application Field

Our products are widely used in communication equipment, industrial control, consumer electronics, medical equipment, aerospace, light-emitting diode lighting, automotive electronics.
